Trapezoidal Aluminum Automation Gripper Head, Precision CNC Machined Robotic Pneumatic Clamping Jaws
|
Trapezoidal Aluminum Automation Gripper Head, Precision CNC Machined Robotic Pneumatic Clamping Jaws
| Place of Origin | GuangDong Dongguan |
| Brand Name | SITUO |
| Certification | ISO9001 & TS16949 |
| Model Number | ST-1000013 |
Product Details
Material:
Al
Category:
Automation Gripper Head
Productname:
AI Hardware Components
Surface Treatment:
Oxidation
Processing Technology:
Turning
Sample Period:
10 To 15 Days
Precision:
Min 0.01
Head Shape:
Customizable
Manufacturer:
AI Hardware Inc.
Our Service:
One-step Service
Size:
28.0MM
Packing:
Plastic Pallets
Qc Control:
100% Inspectton
Specification:
Customized
Origin:
China
Corrosionresistance:
High
Highlight:
Trapezoidal aluminum robotic gripper head
,Precision CNC machined pneumatic jaws
,Automation clamping jaws with warranty
Payment & Shipping Terms
Minimum Order Quantity
1PCS
Price
5-10 USD per item
Packaging Details
Communication
Delivery Time
Communication
Payment Terms
T/T
Supply Ability
10000PCS per day
Product Description
Trapezoidal Aluminum Automation Gripper Head, Precision CNC Machined Robotic Pneumatic Clamping Jaws
1. Product Overview
Trapezoidal aluminum automation gripper heads are precision CNC pneumatic clamping components specially designed for irregular, easily slipped and special-shaped workpieces. Different from traditional parallel grippers, they adopt a unique trapezoidal narrow-bottom and wide-top clamping structure, perfectly suited for high-frequency grabbing and high-speed handling of industrial robotic arms and collaborative robots. Manufactured from high-hardness aerospace aluminum alloy via 5-axis CNC integrated precision machining, the gripper jaws feature zero deformation, burr-free surface and accurate tolerance. The trapezoidal inclined surface realizes automatic centering and adaptive fitting for round, tapered and irregular parts, greatly improving grabbing tolerance and stability. With lightweight design and hard anodized surface treatment, these grippers adapt to long-term cyclic automation operation. Both standard size and custom non-standard structures are available.
2. Core Product Advantages
1. Unique Trapezoidal Inclined Structure, Anti-Slip & Anti-Dropping
The wide-entry and narrow-bottom trapezoidal design provides automatic guiding and self-centering functions. It actively corrects workpiece position during clamping and perfectly fits round, tapered and irregular workpieces with low positioning accuracy requirements. Compared with ordinary parallel grippers, it effectively solves slipping, offset and dropping problems during high-speed movement and vibration, greatly improving automation line yield and operational stability.
2. 5-Axis CNC Precision Machining with High Symmetry & Accuracy
Integral 5-axis CNC precision machining strictly controls trapezoidal angle, symmetry, flatness and mounting hole tolerance. The left and right jaws maintain complete symmetry with uniform stress and tight fitting. Batch products feature excellent consistency and interchangeability, ensuring smooth opening and closing without jamming, meeting high-precision repeated grabbing requirements of intelligent robots.
3. Lightweight Aluminum Alloy Reduces Robot End Load
High-strength lightweight aluminum material greatly reduces the weight of robot end-effector compared with steel clamps. It lowers motion inertia, improves robot response speed and repeated positioning accuracy, and avoids jitter, delay and high energy consumption caused by heavy fixtures. Ideal for high-speed collaborative robots and miniature manipulator lightweight design.
4. Hard Anodized Surface for Superior Wear & Corrosion Resistance
Hard anodizing treatment enhances surface hardness and wear resistance of trapezoidal clamping surfaces, avoiding edge collapse and deformation after long-term cyclic grabbing. It provides excellent anti-rust, oil-proof and dust-proof performance, adapting to harsh industrial environments and extending service life significantly, reducing equipment maintenance and replacement costs.
5. Full Non-Standard Customization for Special-Shaped Workpieces
We support custom trapezoidal angles, opening ranges, jaw lengths, anti-slip teeth and profiling grooves. Custom solutions are tailored for pipe fittings, tapered parts, irregular plastic parts and fragile precision components, realizing damage-free, centered and stable clamping for personalized automation grabbing processes.
3. Application Scenarios
✅ Robot pneumatic trapezoidal grippers for automatic centering grabbing of irregular workpieces
✅ Automation line clamping heads for round, tapered and special-shaped part handling
✅ Tolerant precision gripper components for 3C electronics, plastic and small hardware parts
✅ Anti-drop trapezoidal clamping jaws matching pneumatic finger cylinders
✅ Special gripper parts for high-speed automated sorting, handling and assembly equipment
4. Quality Assurance & Service
All trapezoidal aluminum gripper heads undergo strict pre-delivery tests, including trapezoidal angle inspection, symmetry calibration, full dimension tolerance testing, opening-closing fatigue simulation and wear resistance testing. Every inclined surface and fitting gap is precisely controlled to ensure centered, stable and anti-slip clamping. We support fast stock delivery, rapid prototyping, custom non-standard processing and stable mass production, providing high-tolerance, high-stability and long-life precision grabbing solutions for global intelligent robot and automation equipment manufacturers.
We have introduced advanced equipment and technology from Japan and Germany (CNC 5-axis and 6-axis machines) to better serve our customers' needs.
Our maximum processing outer diameter is 60, and the minimum control tolerance is 0.001. We have Japanese CNC Tsugami, CNC Citizen, multi-station cold extrusion forming machines, 500T press machines, casting equipment, and various process equipment, which can effectively provide customers with the best technical solutions.
Our company has a total of 300 employees, including 20 technicians, 10 engineers, and 15 quality control personnel. We have over 300 pieces of equipment.
Our company implements 8S management and has passed ISO9001 and TS16949 automotive certifications.
Our customers include , bo-sch, Foxconn, Motors, Husqvarna, Shimano, NVIDIA, DJI Drones, Siegenia, and Cater-pillar.
| OUR CAPACITY | ||||
| Main product names: | Stainless steel screws, carbon steel screws, pins, rivets, nuts, | |||
| eccentric nails, embedded parts, and other fasteners. | ||||
| Business Type | Factory / Maufacture | |||
| Service | CNC Machining | |||
| Turning and Milling | ||||
| CNC Turning | ||||
| Cold heading | ||||
| stamping | ||||
| Assembly Service | ||||
| Material | 1). Aluminum: AL 6061-T6, 6063, 7075-T etc | |||
| 2). Stainless steel:303,304,304L,316L,316F,630,410,420,430, etc | ||||
| 3). Steel: 4140, Q235, Q345B,20#,45# 1215,12L14 ,1144,1006,1008,1010,1015,1018 ,10B21,1035,1065 etc. | ||||
| 4)Alloy steel:5140,4135,4140,3435,5120,415 ,435,440 etc | ||||
| 5). Titanium: TA1,TA2/GR2, TA4/GR5, TC4, TC18 etc | ||||
| 6). Brass: C36000 (HPb62), C37700 (HPb59), C26800 (H68), C22000(H90),C27000,C51900,C11000,C3604,H62,H65 etc | ||||
| 7). Copper, bronze, Magnesium alloy, Delrin, POM,Acrylic, PC, etc. | ||||
| Finish | Sandblasting, Anodize color, Blackenning, Zinc/Nickl Plating, Polish, | |||
| Power coating, Passivation PVD, Titanium Plating, Electrogalvanizing, | ||||
| electroplating chromium, electrophoresis, QPQ(Quench-Polish-Quench), | ||||
| Electro Polishing,Chrome Plating, Knurl, Laser etch Logo, etc. | ||||
| Drawing format | STEP,STP,GIS,CAD,PDF,DWG,DXF etc or samples. | |||
| Tolerance | +/-0.01mm ~ +/-0.05mm | |||
| Surface roughness | Ra 0.1~3.2 | |||
| Inspection | Complete inspection lab with Micrometer, Optical Comparator, Caliper Vernier,CMM | |||
| Depth Caliper Vernier, Universal Protractor, Clock Gauge, Internal Centigrade Gauge | ||||
